| ITEM # | PART # | DESCRIPTION | QTY. | UNIT |
| 1 | 47106737 | BEARING ASSEMBLY | 2 | EA |
| NS | 47106794 | BEARING ONLY | 2 | EA |
| 2 | 47106594 | SIDE SEAL ASSEMBLY | 2 | EA |
| 3 | 47106739 | HEAD PROTECTOR YELLOW | 2 | EA |
| 4 | 47106740 | LOCK CATCH | 2 | EA |
| 5 | 47106759 | CATCH MOUNTING PLATE - LH (CS) | 1 | EA |
| 6 | 47106758 | CATCH MOUNTING PLATE - RH (RS) | 1 | EA |
| NS | 47106743 | 5/16 X 1" HEX HEAD BOLT | 4 | EA |
| 7 | 47106744 | 5/16” -18 KEEP NUT | 4 | EA |
| 8 | 47106745 | 1/4 -20 X 1-1/2” HEX HEAD BOLT | 2 | EA |
| 9 | 47106746 | 1/4-20 KEEP NUT | 2 | EA |
| 10 | CALL W/ S/N | VERTICAL TRACK ASSEMBLY CURBSIDE | 1 | EA |
| 11 | CALL W/ S/N | VERTICAL TRACK ASSEMBLY ROADSIDE | 1 | EA |
| 12 | CALL W/ S/N | HORIZONTAL TRACK ASSEMBLY CURBSIDE | 1 | EA |
| 13 | CALL W/ S/N | HORIZONTAL TRACK ASSEMBLY ROADSIDE | 1 | EA |
| NS | CALL W/ S/N | TRACK COUPLER | 2 | EA |
| 15 | CALL W/ S/N | COUNTER BALANCE ASSEMBLY | 1 | EA |
| 16 | CALL W/ S/N | COUNTERBALANCE SHAFT - 62” | 1 | EA |
| 17 | 47106820 | SPRING .156 X 2 3/16 X 17 (LH) C | 1 | EA |
| 18 | 47106821 | SPRING .156 X 2 3/16 X 17 (RH) C | 1 | EA |
| 19 | 47106822 | TORSIONER, MOQ 500 (TG-WINDER) | 1 | EA |
| 20 | 47106823 | BASE PLATE, TORSION WINDER BASE PLATE | 1 | EA |
| 21 | 47106727 | 95" 7 X 19 SS CABLE 1/4" METAL EYE | 2 | EA |
| 22 | CALL W/ S/N | WINDING CONE | 2 | EA |
| 23 | CALL W/ S/N | AL. CABLE DRUM & 2 BEARING ASSEMBLIES CS | 1 | EA |
| 24 | CALL W/ S/N | AL. CABLE DRUM & 2 BEARING ASSEMBLIES RS | 1 | EA |
| 25 | CALL W/ S/N | 21" SPACER TUBER | 2 | EA |
| ITEM # | PART # | DESCRIPTION | QTY. | UNIT |
| 28 | 47106796 | LIFT HANDLE - BLACK | 1 | EA |
| 29 | 47106813 | 1-3/8" STAINLESS STEEL RIVET | 8 | EA |
| 30 | 47106774 | L-HANDLE, NON-KEYED | 1 | EA |
| 31 | 47106803 | Screw 10-24 X 1-1/4" Stainless | EA | EA |
| 32 | 47106784 | 10-24 SS Nylok Nut | EA | EA |
| 33 | 47106727 | 95" 7 X 19 SS CABLE 1/4" METAL EYE | 2 | EA |
| 34 | 47106762 | BUTTERFLY CABLE ANCHOR BRACKET | 2 | EA |
| 35 | 47106706 | PIN CABLE ANCHOR BRACKET | 2 | EA |
| 36 | 47106719 | COTTER PIN | 2 | EA |
| 37 | CALL W/ S/N | PANEL BOTTOM COMPOSITE - COMPLETE | 1 | EA |
| 38 | CALL W/ S/N | PANEL LATCH COMPOSITE - COMPLETE | 1 | EA |
| 39 | CALL W/ S/N | PANEL INTERMEDIATE COMPOSITE | 1 | EA |
| 40 | CALL W/ S/N | PANEL TOP COMPOSITE - COMPLETE | 1 | EA |
| 41 | 47003621 | TOP PANEL SEAL RETAINER | 1 | EA |
| 42 | 47009914 | TOP PANEL SEAL - STANDARD | 1 | EA |
| 45 | 47106801 | TOP CLOSURE COMPLETE | 2 | EA |
| 46 | 61419 | END HINGE | 10 | EA |
| 47 | 61397 | CENTER HINGE | 10 | EA |
| 48 | 47106728 | 12" PULL STRAP, NO LOOP - 2 BLACK RETAINERS | 1 | EA |
| 49 | 47009944 | 1-1/8" STAINLESS STEEL RIVET | 24 | EA |
| 50 | 47106802 | 60" PULL STRAP, NO LOOP - 2 BLK RETAINERS | 1 | EA |
| 51 | 47003694 | HD BOTTOM FIXTURE ASSEMBLY - RS | 1 | EA |
| 52 | 47003685 | HD BOTTOM FIXTURE ASSEMBLY - CS | 1 | EA |
| 53 | 47106804 | CABLE COVER W/ STUDS - 62" LENGTH | 1 | EA |
| 54 | 47106717 | 2 PT END LATCH - RS | 1 | EA |
| 55 | 47106702 | CABLE ASSEMBLY, 2 PT LOCK W/ 2 STOPS & WASHER | 1 | EA |
| 56 | 47106712 | CENTER CONTROL ASSEMBLY | 1 | EA |
| 57 | 47106805 | LOCK COVER BASE CENTER | 1 | EA |
| 58 | 47106806 | LOCK COVER BASE END | 2 | EA |
| 59 | 47106716 | 2 PT END LATCH - CS | 1 | EA |
| 60 | 47106807 | 1" PREMIUM NYLON ROLLER | 14 | EA |
| 61 | 47106718 | SPACER WASHERS | 16 | EA |
| 62 | 47106808 | BOTTOM ANGLE FOR .75" COMPOSITE DOOR | 1 | EA |
| 63 | 47009943 | 1" STAINLESS STEEL RIVET | 32 | EA |
| 64 | 47106813 | 1 3/8" STAINLESS STEEL RIVET | 8 | EA |
| NS | 47000839 | HEADER SEAL ASSEMBLY - 60" (CUT TO 56.625") | 1 | EA |
