| Item # | Part # | Description | QTY. | UNIT |
| 1 | Call W/ S/N | .25" Composite Top Panel- Complete- 13.5" x 58.75" w/ Seal | 1 | EA |
| 2 | Call W/ S/N | .25" Composite Intermediate Panel - 13" x 58.75" | 1 | EA |
| 3 | Call W/ S/N | .25" Composite Intermediate Panel - 15" x 58.75" | 1 | EA |
| 4 | Call W/ S/N | .25" Composite 2Pt Lock Panel- Complete 15" x 58.75" | 1 | EA |
| 5 | Call W/ S/N | .25" Composite Bottom Panel -Complete 15" x 58.75" | 1 | EA |
| 6 | 47106772 | Cable 110" 7 x 19 SS 1/4 Aluminum Eye (Each) | 2 | EA |
| 7 | 47106762 | Cable Anchor Bracket | 2 | EA |
| 8 | 47106706 | Pin - Cable Anchor 1/4" X 1" | 2 | EA |
| 9 | 47106719 | Cotter Pin 3/32" X 1" | 2 | EA |
| 10 | 47106774 | L-Handle, Non-keyed | 1 | EA |
| 11 | 47106796 | Lift Handle - Black (2 5/8" SS) | 1 | EA |
| 12 | 47106782 | Top Panel Seal Assembly - 58.75 | 1 | EA |
| 13 | 47106710 | Top Closure Assembly Complete | 2 | EA |
| 14 | 47106711 | Top Closure Slide Only | - | EA |
| 15 | 47106797 | End Hinge Assembly - Heavy Duty (5/16" Studs) | 10 | EA |
| NS | 47106776 | End Hinge - Base Only | - | EA |
| 16 | 47106760 | End Hinge - Cover Only - Heavy Duty | - | EA |
| 17 | 47106731 | Center Hinge-Heavy Duty | 10 | EA |
| 18 | 47106764 | 3 Stud Bottom Fixture Assembly -Complete | 2 | EA |
| 19 | 47106763 | Roller Clamp, 3 hole Roller Clamp for 2" Rollers | - | EA |
| 20 | 47106833 | 2" Nylon Roller | 14 | EA |
| 21 | 47106891 | Center Control Complete w/ Lift Handle | 1 | EA |
| 22 | 47106767 | Latch Base Center - .91" Offset, 2" Track | 1 | EA |
| 23 | 47106769 | Two Point End Latch Assembly- Curbside | 1 | EA |
| 24 | 47106770 | Two Point End Latch Assembly- Roadside | 1 | EA |
| 25 | 47106806 | Latch Base - End Latch | 2 | EA |
| 26 | 47106740 | Lock Catch | 2 | EA |
| 27 | 47106761 | Cable Assy. 24.75" with (2) Stops & Washer (EACH) 2 | 2 | EA |
| 28 | 47106768 | Aluminum Cable Cover - 58.375" Length - 7.5mm Comp, | 1 | EA |
| 29 | 47106773 | 52" No Loop Strap W/ 1" Sewn Loop - Black Retainer | 1 | EA |
| 30 | 47106869 | Retainer Only - Black | - | EA |
| 31 | 47106718 | Spacer Washer | 16 | EA |
| 32 | 47106686 | Header Brush Seal Assembly | 1 | EA |
| 33 | Call W/ S/N | Seal Bottom Edge 4 Point Rubber 58.75" | 1 | EA |
| 34 | Call W/ S/N | Angle - Bottom Seal Black 58.75" | 1 | EA |
| Item # | Part # | Description | QTY. | UNIT |
| 35 | 47106737 | Bearing Assembly | 2 | EA |
| 36 | 47106687 | Side Seal - Bolt on Style, 85.25" - EA | 2 | EA |
| 37 | 47106787 | 2" Head Protector Yellow | 2 | EA |
| 38 | Call W/ S/N | Vertical Track Assembly - Curbside | 1 | EA |
| 39 | Call W/ S/N | Vertical Track Assembly - Roadside | 1 | EA |
| 40 | Call W/ S/N | Horizontal Track Assembly - Curbside | 1 | EA |
| 41 | Call W/ S/N | Horizontal Track Assembly - Roadside | 1 | EA |
| NS | Call W/ S/N | Counterbalance Assembly | 1 | EA |
| 43 | 47106753 | Cable Drum LH Roadside | 1 | EA |
| 44 | 47106754 | Cable Drum RH Curbside | 1 | EA |
| 45 | 47106755 | Counterbalance Shaft - 58.75" | 1 | EA |
| NS | 47106794 | Bearing Only | 2 | EA |
| 47 | Call W/ S/N | Spring .207 x 2.48 x 30 RH Coated | 1 | EA |
| 48 | Call W/ S/N | Anchor Bracket Clipped | 1 | EA |
| 49 | Call W/ S/N | Anchor Bracket Curbside | 1 | EA |
| 50 | Call W/ S/N | Anchor Bracket Roadside | 1 | EA |
| 51 | 47003643 | Spring Winding Plug 2-1/2" | 1 | EA |
| 52 | Call W/ S/N | Spring Winding Plug 2-1/2" | 1 | EA |
