47106770
| Item # | Part # | Description |
| 1 | 47106796 | Lift Handle - Black (2 5/8" SS) |
| 2 | 47106762 | Cable Anchor Bracket |
| 3 | 47106706 | Pin - Cable Anchor 1/4" X 1" |
| 4 | 47106719 | Cotter Pin 3/32" X 1" |
| 5 | 47106766 | Backplate Safety Chain - BLK |
| 8 | 47106724 | 1/4" x 5/8" SS Semi Tubular Rivet |
| 9 | 47106725 | 1/4" x 3/4" SS Semi Tubular Rivet |
| 11 | 47106772 | Cable 110" 7 x 19 SS 1/4 Aluminum Eye (Each) |
| 13 | 47106774 | L-Handle, Non-keyed |
| 14 | 47106777 | .25" Composite Top Panel- Complete- 13.5" x 58.75" w/ Seal |
| 15 | 47106778 | .25" Composite Intermediate Panel - 13" x 58.75" |
| 16 | 47106779 | .25" Composite Intermediate Panel - 15" x 58.75" |
| 17 | 47106781 | .25" Composite 2Pt Lock Panel- Complete 15" x 58.75" |
| 18 | 47106780 | .25" Composite Bottom Panel -Complete 15" x 58.75" |
| 19 | 47106782 | Top Panel Seal Assembly - 58.75 |
| 20 | 47106760 | Roller Hinge Cover |
| 21 | 47106797 | End Hinge Assembly Heavy Duty |
| 22 | 47106761 | Cable Assy. 24.75" with (2) Stops & Washer (EACH) 2 |
| 23 | 47106763 | Roller Clamp, 3 hole Roller Clamp for 2" Rollers |
| 24 | 47106764 | 3 Stud Bottom Fixture Assembly -Complete |
| 25 | 47106765 | 2" High Cycle Steel Roller |
| 26 | 47106718 | Spacer Washer |
| 27 | 47106710 | Top Closure Assembly Complete |
| 28 | 47106711 | Top Closure Slide Only |
| 29 | 47106712 | Center Control Complete |
| 30 | 47106767 | Latch Base Center - .91" Offset, 2" Track |
| 31 | 47106768 | Aluminum Cable Cover - 58.375" Length - 7.5mm Comp, |
| 32 | 47106769 | Two Point End Latch Assembly- Curbside |
| 33 | Two Point End Latch Assembly- Roadside | |
| 34 | 47106731 | Center Hinge-Heavy Duty |
| 35 | 47106773 | 52" No Loop Strap W/ 1" Sewn Loop - Black Retainer |
| 36 | 47106686 | Header Brush Seal Assembly |
| NS | 47106720 | Buck Rivet - 11/16" |
| NS | 47106721 | Buck Rivet - 13/16" |
| NS | 47106771 | 5/16" Nylok Nut |
| NS | 47106723 | 1/4" Nylok Nut |
| NS | 47106726 | 1/4" x 7/8" SS Semi Tubular Rivet |
| NS | 47106783 | 10-24 x 1" SS Flat Head Screw |
| NS | 47106784 | 10-24 SS Nylok Nut |
| Item # | Part # | Description |
| 45 | 47106737 | Bearing Assembly |
| 46 | 47106687 | Side Seal - Bolt on Style, 85.25" - EA |
| 47 | 47106787 | 2" Head Protector Yellow |
| 48 | 47106740 | Lock Catch |
| 49 | 47106743 | 5/16" x 1" Hex Head Bolt grade 5 |
| 50 | 47106744 | 5/16 Keep Nut |
| 51 | 47106788 | 1/4 -20 x 2 1/2" Hex Head Bolt |
| 52 | 47106746 | 1/4" Kep Nut |
| 53 | 47106789 | Vertical Track Assembly - #47106044- Curbside |
| 54 | 47106790 | Vertical Track Assembly - #47106044- Roadside |
| 55 | 47106791 | Horizontal Track Assembly- #47106044- Curbside |
| 56 | 47106792 | Horizontal Track Assembly- #47106044- Roadside |
| 57 | 47106793 | Counterbalance Assembly - #47106044 |
| 58 | 47106743 | 5/16" x 1" Hex Head Bolt grade 5 |
| 59 | 47106753 | Cable Drum LH |
| 60 | 47106754 | Cable Drum RH |
| 61 | 47106755 | Counterbalance Shaft - 58.75" |
| 62 | 47106794 | Bearing Only |
